Description Description SPECIFICATIONS Camera Image Sensor 1/2.8″ CMOS Signal System PAL/NTSC Min. Illumination Color: 0.02Lux@ (F2.0, AGC ON), B/W: 0Lux with IR Shutter Time 1s to 1/100,000s Day & Night Dual IR Cut Filter with Auto Switch Wide Dynamic Range Digital WDR Angle Adjustment Flexible Lens Lens Type Fixed Focus 2.8mm/4mm Lens Mount M12 Aperture F2.0, Fixed FOV Horizontal field of view: 99.7° (2.8mm)/83.3°(4mm) Illuminator IR LEDs 2 IR Range Up to 40 m Wavelength 850nm White LEDs/Warmlights N/A Compression Standard Video Compression S 265/H.265/H.264 Video Bit Rate 32 Kbps~6 Mbps Audio Compression N/A Audio Bit Rate N/A Image Max. Resolution 1920 1080 Main Stream PAL: 25fps (1920 1080, 1280 720, 704 576, 640 480) NTSC: 30fps (1920 1080,1280 720, 704 480, 640 480) Sub Stream PAL: 25fps (704 576, 704 288, 640 360, 352 288) NTSC: 30fps (704 480, 704 240, 640 360, 352 240) Third Stream N/A Image Setting Saturation, brightness, contrast, sharpness, adjustable by client software or web browser Image Enhancement BLC/3D DNR/HLC ROI N/A OSD 16 16, 32 32, 48 48, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions Picture Overlay N/A Privacy Mask Yes, 4 regions Smart Defog Yes Feature Alarm Trigger Motion Detection, Mask Alarm, IP Address Conflict Video Analytics Tripwire, Perimeter Early Warning(EW) N/A Network ANR Yes(Only Support Tiandy ANR NVR) Protocols TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, IPV4, NTP, UDP, Telnet, ICMP, RTP, RTSP, UPnP System Compatibility ONVIF (PROFILE S/T/G), SDK, P2P(Mutually exclusive with Profile G) Remote Connection 7 Client Easy7, EasyLive Web Version Web5 Interface Communication Interface 1 RJ45 10M/ 100M self adaptive Ethernet port Audio I/O N/A Alarm I/O N/A Reset Button Yes On-board storage N/A General Firmware Version – Web Client Language 15 languagesEnglish, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai, French, Polish, Dutch, Hebraism, Arabic, Vietnamese Operating Conditions -40 ～65 , 0～95% RH Power Supply DC 12V±25%, PoE (802.3af) Power Consumption MAX: 6W(12V) MAX: 7W(POE) Protection IP68, Lightning protection, surge protection and voltage transient protection meets EN 55035:2017 Heater N/A Dimensions 100*118*170mm Weight 2.5-3KG *Listed resolutions are only selectable options. It does not mean that all streams can work at their maximum resolution at the same time. Application Environments: This is a miniaturized, infrared integrated, and intelligent Ex-Proof Anti-corrosion monitoring equipment. It can be widely used in petroleum, chemical industry, oil depots, ships,Vessels ,Marine, drilling platforms, gas stations, gas stations, ports, mines, aerospace, Military industry, steel, pharmaceutical, fireworks production, food processing and other places. It has a built-in infrared lighting chip, which automatically turns on the infrared light at night or when the visible light is insufficient. It adopts a window design with the camera to completely eliminate the infrared light halo and can monitor dangerous places all-weather.The window is special tempered flat glass, the light transmittance is higher than 95%, while being sturdy and durable, it ensures the clear image.Optional low-temperature automatic heating function, automatic heating components can ensure that the equipment can work stably for a long time under the temperature condition of -30℃ to 60℃ to prevent condensation.The protection grade reaches IP68, the stainless steel Sunshield is adopted, the structure is firm and fully sealed, which represents the current high standard of environmental protection.Also widely used for marine safe environment
